Bow Windows by Winmax Toronto
A series of four or more adjoining bow window units, commonly five in number, installed on a radius from the wall of the building. These types of windows can be installed with head and seat boards.
- Bow windows are window units made up of 4 to 6 windows in a graceful arc shape with a shallow insulated seat.
- Bow windows typically have fixed center windows with operating casements on the ends.
- You may be able to upgrade an existing window opening to a bow.
THEN & NOW
BUILT TO LAST
BRILLIANT SASH BALANCES
SECURE WHILE EASY TO ACCESS
ONLY THE FINEST VINYL
SEAL LIKE NO OTHER
LOCK TILT MECHANISM
BUILT IN SASH HANDLE
BEST QUALITY SCREENS
|IG Type and Coating||visible light||fade transition||solar||U-Factor|
|transmittance||external reflectance||internal reflectance||UV||ISO||Heat gain coefficient||air fill||argon fill|
Vinyl Package Sizes
- Jamb sizes: 1-1/2″, 2-1/2″, 3-3/8″, 4-5/8″
- Casing sizes: 2-5/8″, 3-3/8″
- Rosette sizes: 2-5/8″, 3-3/8″
This operator will provide a full 90 degrees of window opening and disconnects easily from the sash for cleaning.
This operator features a peak operating torque approximately 28% lower than Truth’s Traditional Single Arm Operators (depending on mounting location).
The Full-Flip Handle design is engineered to help maintain its “open” position without retracting in on itself during operation. The handle provides smooth operation with a more contemporary look when nested and allows for easy screen removal without removing the crank.
|Style||Material||Brand Name||Product Name||Model||Glaze||SHGC||Energy Rating||Umet||Uimp||ENERGY STAR Zone(s)|
|High Profile Fixed||Vinyl||Hometech||Contour Series||400||2||0.57||35||1.65||0.29||ABCD|
|Low Profile Fixed||Vinyl||Hometech||Contour Series||400A||2||0.57||39||1.65||0.29||ABCD|
|Single Hung||Vinyl||Hometech||Contour Series||250||2||0.53||33||1.79||0.32||ABC|
|Single Slider||Vinyl||Hometech||Contour Series||200||2||0.53||30||1.8||0.32||ABC|
|Double Slider||Vinyl||Hometech||Contour Series||300||2||0.5||31||1.81||0.32||AB|
|Casement (single)||Vinyl||Hometech||Contour Series||100||2||0.43||30||1.69||0.3||AB|
|Fixed casement||Vinyl||Hometech||Contour Series||150A||2||0.44||28||1.7||0.3||AB|
|Fixed casement||Steel||Hometech||Contour Series||150||2||0.42||28||1.67||0.29||AB|
|Double Hung||Vinyl||Hometech||Contour Series||350||2||0.5||31||1.8||0.32||AB|
|Awning (single)||Vinyl||Hometech||Contour Series||125||2||0.45||29||1.74||0.31||AB|
|Casement (single)||Vinyl||Hometech||Contour Series||100A||2||0.44||30||1.74||0.31||AB|
Energy Efficiency Values
Umet = U-value (W/m_ – K) – The lower the number, the more energy efficient the product.
Uimp = U-value (Btu/h*ft2*F) – The lower the number, the more energy efficient the product.
SHGC = Solar Heat Gain Coefficient – The higher the number, the higher the solar gain.
ER = Energy Rating (W/m2 or dimensionless) – The higher the number, the more energy efficient the product.
The ER (Energy Rating) format was changed to all positive numbers (dimensionless) in October, 2004 by CSA (Canadian Standards Association) to address consumer confusion over negative numbers. The older format had a mixture of negative and positive numbers (W/m2). In our listings, all ER numbers that appear in the older format are shown in bold coloured type. An approximate conversion to the new format can be made by adding 33 to these numbers.
