Winmax Slider Tilt-in windows are uniquely beautiful ENERGY STAR rated high-efficiency windows. Contoured and stylish they have one operating sliding sash with screen and one fixed side. They can be cleaned with the lower sash tilted in and can be combined with picture windows for wide openings. Stylish Georgian contoured styling enhances beauty while increasing energy efficiency. These windows come with an optional night latch for security and accommodate window type A/C units.
Single sliding tilt windows offer the best of both world in window design. The two-pane window has one immobile sash and a mobile sash which opens by sliding the sash from one side to the other along smooth built-in tracks. Once open, the sliding window pane has the option of being tilted outward like a door. This not only helps better direct air flow, but it also adds to the visual appeal of the single slider design. A secure screen installed on the mobile side of your single sliding window which provides an uninterrupted view of the outside while adding some protection from unwanted insects and other intruders.
Single Slider Windows Toronto
Single slider tilt windows have always been popular in window styles because while it simplistic in design, the window type easily adds to the curb appeal and resale value of your home. Single sliding windows are one of the more cost effective window types and are easy to open and close. A latch system is used to close and lock the window so it cannot be opened from the outside. The latch locking system also helps seal the window so your home is better protected from undesirable weather elements. Once closed the secure seal prevents drafts and moisture from entering your home so you can better control your room temperature. When open, single slider tilt windows offer ample ventilation while letting plenty of natural light in your home.
Single sliding windows are ideal in smaller rooms with minimal space. They work well in bathrooms and bedrooms. Single slider tilt windows are also commonly used in basement or lower level rooms because they are a better fit for the smaller areas. The sliding feature of the single sash also makes it easier to open the windows in lower or smaller areas.Price: Starting From $199
THEN & NOW
BUILT TO LAST
BRILLIANT SASH BALANCES
SECURE WHILE EASY TO ACCESS
ONLY THE FINEST VINYL
SEAL LIKE NO OTHER
LOCK TILT MECHANISM
BUILT IN SASH HANDLE
BEST QUALITY SCREENS
|IG Type and Coating||visible light||fade transition||solar||U-Factor|
|transmittance||external reflectance||internal reflectance||UV||ISO||Heat gain coefficient||air fill||argon fill|
Vinyl Package Sizes
- Jamb sizes: 1-1/2″, 2-1/2″, 3-3/8″, 4-5/8″
- Casing sizes: 2-5/8″, 3-3/8″
- Rosette sizes: 2-5/8″, 3-3/8″
This operator will provide a full 90 degrees of window opening and disconnects easily from the sash for cleaning.
This operator features a peak operating torque approximately 28% lower than Truth’s Traditional Single Arm Operators (depending on mounting location).
The Full-Flip Handle design is engineered to help maintain its “open” position without retracting in on itself during operation. The handle provides smooth operation with a more contemporary look when nested and allows for easy screen removal without removing the crank.
|Style||Material||Brand Name||Product Name||Model||Glaze||SHGC||Energy Rating||Umet||Uimp||ENERGY STAR Zone(s)|
|High Profile Fixed||Vinyl||Hometech||Contour Series||400||2||0.57||35||1.65||0.29||ABCD|
|Low Profile Fixed||Vinyl||Hometech||Contour Series||400A||2||0.57||39||1.65||0.29||ABCD|
|Single Hung||Vinyl||Hometech||Contour Series||250||2||0.53||33||1.79||0.32||ABC|
|Single Slider||Vinyl||Hometech||Contour Series||200||2||0.53||30||1.8||0.32||ABC|
|Double Slider||Vinyl||Hometech||Contour Series||300||2||0.5||31||1.81||0.32||AB|
|Casement (single)||Vinyl||Hometech||Contour Series||100||2||0.43||30||1.69||0.3||AB|
|Fixed casement||Vinyl||Hometech||Contour Series||150A||2||0.44||28||1.7||0.3||AB|
|Fixed casement||Steel||Hometech||Contour Series||150||2||0.42||28||1.67||0.29||AB|
|Double Hung||Vinyl||Hometech||Contour Series||350||2||0.5||31||1.8||0.32||AB|
|Awning (single)||Vinyl||Hometech||Contour Series||125||2||0.45||29||1.74||0.31||AB|
|Casement (single)||Vinyl||Hometech||Contour Series||100A||2||0.44||30||1.74||0.31||AB|
Energy Efficiency Values
Umet = U-value (W/m_ – K) – The lower the number, the more energy efficient the product.
Uimp = U-value (Btu/h*ft2*F) – The lower the number, the more energy efficient the product.
SHGC = Solar Heat Gain Coefficient – The higher the number, the higher the solar gain.
ER = Energy Rating (W/m2 or dimensionless) – The higher the number, the more energy efficient the product.
The ER (Energy Rating) format was changed to all positive numbers (dimensionless) in October, 2004 by CSA (Canadian Standards Association) to address consumer confusion over negative numbers. The older format had a mixture of negative and positive numbers (W/m2). In our listings, all ER numbers that appear in the older format are shown in bold coloured type. An approximate conversion to the new format can be made by adding 33 to these numbers.
